12W 4" LED Slim Recessed Downlight Square

The recessed 3", 4", 6", 8" downlights are a long life and energy efficient replacement for traditional lamps. This 0.87" ultra luminaire is the thinnest. Smooth beam distribution and superior color quality for better visual comfort. The LED downlights are 2700-5000K color temperature for your option and offer full dimming capability to satisfy more application needs in residential and commercial settings.

CertificationFeatureApplication
  • FEATURE AND BENEFIT
  • SPECIFICATION
  • DOCUMENTATION
  • Feature:

    -Die cast aluminum housing routes heat away from electrical components

    -120V Input, 50/60Hz

    -PF>0.9

    -CRI80/90 option

    -High quality PMMA light guide plate creates uniform light, edge to edge

    -Available in wide range of color temperature from 2700-5000K

    -5 year limited warranty

    -Smooth dimming feature and compatible with a wide variety of dimmers


    Benefit:

    -Use 1/4 of the power of traditional halogen lights

    -Edge lit technology allows for extremely thin fixture depth

    -Easy to install, no housing required

    -No UV or IR radiation

    -ETL Classification for WET location usage

    -Energy Star qualify

    -Adjustable, spring loaeded retention tabs ensure secure fixture retention

    -Perfect for areas that need to be lit during long period of time

  • Watts

    		12W

    Trim Size(Inch)

    		4

    CRI

    		80/90
    Item NumberHT-G6W#SSD4-C12-XXS-ZZ
    Lumens950/850LM
    Efficacy(lm/w)79/70
    Life span(Hr)50000
    MOL(Inch)1.02
    MOD(Inch)5.04
    Weight(Lb)0.86
    DimmableY
